Plastic HDPE extrusion blow molding machine 5L for oil pot
Introduction
This series is single station mold-moving machine, high efficiency and stability, suitable for making 1-5L containers in small batch production. It adopts central-incoming extrusion die head which can be divided into single layer, double layer and transparent line type. Mold-moving adopts buffering throttle valve. Hydraulic system adopts differential design, mold-moving stable, high efficiency, and fast speed.
Hollow plastics blow moulding machine can produce all kinds of PE Container, PP Container, ABS Container, PC Container. likes oil buckets, toolbox, chairs,jerrycans, desks,hollow parts and so on.
PLC plus man-machine interface, operate by touch screen. Self-diagnosis alarm, clear at a glance.
Accumulator die head whose runner is made by high-quality nitride alloy steel with mirror surface treatment, material and color quick reload.
Unique " three tie bar +two cylinder + linear guide" structure of the clamping structure to ensure a more uniform mode-lock, knit line more smooth.
Hydraulic system designed under energy-saving hydraulic principles,adopt two oil pump structure. lower energy consumption by 20% -40% compared with the conventional model. At the same time, a significant reduction in oil temperature extends the service life of hydraulic parts.
Variety of functions for different products matching the technological requirements: bottom blow and lift, rotation, encapsulation, material support, sub-mould, robot, parison control system ,etc.
Feature
1. Reasonable structure design and solid frame manufacturing to insure running stability.
2. Good head material runner deisgn and precision metal process for changing color easily.
3. According to your specified request, our machine can be made with co-extrusion of 2~4 layers and view stripe line.
4. Colorful touch screen, cantilever operation box, bottle collective shelves, scraps sliding channel and safety protection.
5. Total machine control system well match with scraps on-line deflashing, angle adjustable blowing unit, neck rotary cutting, in-mould labeling, weight testing and leakage testing, product conveying & packing.
Parameter
SPECIFICATIONS & TECHNICAL DATA
|
|
|
Screw Diameter
|
mm
|
80
|
|
Plasticizing Capacity
|
Kg/hour
|
110
|
|
Temperature Control Zone
|
No.
|
5
|
|
|
Single Head Max Die Diameter
|
mm
|
230
|
|
Double Head Central Distance
|
mm
|
230
|
|
Four Head Central Distance
|
mm
|
120
|
|
Six Head Central Distance
|
mm
|
85
|
|
|
Clamping Force
|
KN
|
110
|
|
Platen Size
|
mm
|
580x420
|
|
Opening Distance
|
mm
|
150~450
|
|
Moving Distance
|
mm
|
720
|
|
Max Mould Size
|
mm
|
630x385
|
|
|
Extrusion Motor Power
|
KW
|
30
|
|
Pump Motor Power
|
KW
|
15
|
|
Machine Total Power
|
KW
|
72
|
|
Average Power Consumption
|
KW
|
42
|
